UHD-100A
주요기능:
UHD 해상도 POV 카메라
UHD-100A는 AIDA 특유의 작고 견고한 카메라 바디로부터 선명한 UHD영상을 HDMI 포트를 통해 출력하는 POV 제품입니다.
제품사양
| Image Sensor | 1/2.5″ Progressive CMOS |
| Sensor Size | Diagonal 7.20mm |
| Effective Pixels | Horizontal: 3840, Vertical: 2160 |
| Pixel Size | 1.62 µm (H) x 1.62 µm (V) |
| Resolution | 2160 30p/29.97p/25p/24p 1080 60p/59.94p/50p/30p/ 29.97p/25p/24p 1080 60i/59.94i/50i 720 60p/59.94p/50p/30p/25p |
| Output | HDMI 1.4 |
| Color Space | 4:2:2 (YCbCr) 10bit |
| White Balance | AWB / AE / AF |
| Exposure | Full Auto, Bright, Shutter Priority, Iris Priority, Manual |
| Other | WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction, Digital Slow Shutter, Black Level Compensation, Flicker Detection |
| Lens | C/CS Mount (Default UHD 3.2mm Lens) |
| Input | 3.5mm TRS Stereo Mic-in & Line in over I/O Cable |
| Sample Rate | 16/24/32 Bits |
| Camera Control | RS-485 VISCA, OSD Button |
| Operation Temp | 32° F – 104° F |
| Dimension | 39mm x 39mm x 50.50mm / 1.53″ x 1.53″ x 1.99 |
| Weight | 140g / 0.30lbs |
| Power | 12VDC (+9 – +15VDC) |
